Product function:

Graphical menu operation interface (OSD menu);

User password, administrator password two-level management;

Embedded Linux operating system;

8 channels of 1080 HD audio and video input, 1 channel of video and audio synchronous output, 1 channel of VGA output video compression adopts H.264 algorithm, the system has four modes to choose (1080p, 960p, 720p, D1, CIF, etc.);

It supports 2.5-inch hard disk, up to 2TB, and 2 128gsd cards

Support mouse operation;

Support reversing mirror configuration function;

Proprietary SD card bad track detection technology, not only ensure the continuity of video recording, but also prolong the SD life

Built in super capacitor to avoid abnormal power failure, data loss and disk damage

Support intelligent power management identification, low power automatic shutdown, flameout and low power consumption

Under voltage, short circuit, reverse connection and other protection circuits are suitable for various vehicle models;

Support China Unicom, telecom or mobile 3g network, 4G network;

Support receiving WiFi network;

Support computer and mobile phone real-time remote monitoring; (Android and apple system)

Support global GPS positioning module;

Built in GPS positioning, can record the vehicle's track and speed;

Playing back on PC, it can display the vehicle track and speed on the map;

Support PC playback analysis and local video playback;

Input power supply: 8-48v; output voltage: 12V / 2A;

Working temperature - 20 ℃ - 60 ℃;

Dimension: 230mm * 280mm * 75mm
