Compression mode MJPEG

Video format avi

Audio format wav

Working Voltage 5V

Working current < 150mA (without infrared) / < 420mA (with infrared on)

No battery capacity

Working temperature 85 ° ~ - 30 °

Night vision distance: 5m

The photosensitive area is 3.5964mm x 2.7084mm

Frame rate 15fps

Storage capacity 8g / 16g / 32g TF Card (class10 and above, 2G space, FAT32 file system)

File system FAT32

10 minutes segmented video recording, each video recording is about 70m (depending on the complexity of the shooting scene and the intensity of the picture movement, 70m is a common scene, for reference only), and the capacity of 30g can store about 75 hours of video files

Working mode

The video / recording and TF card space recycling will be started after power on

During video recording, it can support photographing and file transmission

Support short video serial port transmission and short video file transmission instruction

Time synchronization command with GPS terminal is supported

Support OSD time display

Support recording

It supports the button. During the recording process, you need to get the card to watch the latest video. If you press 2M and release the button, the recording will stop and the TF card can be taken out;

When there is no TF card, it supports photographing; insert TF card to record video automatically
